VENTIS

VENTIS 110

PASSIVE REINFORCEMENT SPEAKER 300W / 8OHM - 127DB SPL

processor

digital processor

mount

pole mounted

hardware for permanent installations

Click on the image to zoom
Technical Specifications
Code: 40682
Configuration: 2 way
Recommended amplifier: 300 W RMS
Long Term power: 150 W
Short term power: 600 W
Nominal impedance: 8 ohm
Frequency response: 60Hz - 18KHz -6dB
Low Frequency woofer: 10 - 2 coil inch
High frequency driver: 1 - 1.4 coil inch
Sensitivity (@1W/1m): 97 dB
Maximum SPL cont/peak: 122/127 dB
Dispersion: 80° x 50° rotatable HxV
Crossover Frequency: 1.8 KHz
Recommended HP filter: HP 50Hz - 12-24dB/oct
Recommended external filter:
Input connector: 2 x SPEAKON
Net Dimension (WxHxD): 329x575x325 / 12.95x22.63x12.79 mm/inch
Net Weight: 15.1/33.28 kg/lb
DOWNLOAD
  • User Manual VENTIS 110
  • GLL for EASE and FOCUS3
  • Datasheet Ventis 110
  • GLL Release Note
Accessories
VN-U110
